Key Features
- Pulsation resistant, glycerin filled stainless steel case
- Lead free wetted parts
- ±1.5% accuracy
- Restricted orifice
- Crimp-On bezel
Specifications
| Brand | Winters Instruments |
| Manufacturer | Winters |
| Model | PFQ801LF |
| Material | Stainless Steel,Lead |
| Color | White |
| Style | 30" Hg VAC/kPa |
| Product Type | ELECTROMECHANICAL_GAUGE |
| Included Components | Unit^Instruction Guide |
| Item Type Keyword | industrial-pressure-gauges |
| Item Dimensions | H: 51 / L: 127 / W: 102 |
| Package Dimensions | H: 40 / L: 116 / W: 78 (Weight: 230) |
| unit |
Description
Applications: Ideal for plumbing, heating, air conditioning, pumps, compressors and pneumatic equipment. Pulsation resistant, liquid filled stainless steel case. CRN registered. Dial: White aluminum with black and red markings. Lens: Polycarbonate. Fill Fluid: Glycerin. Case: 304 SS. Socket: Lead Free Brass. Bourdon Tube: Lead free phosphor bronze C or coil shaped. Movement: Brass. Socket Gasket: Buna N for two-piece internal socket seal. Working Pressure: Maximum 75% of full scale value. Over Pressure Limit: 25%. Ambient Temperature: -4°F to 150°F (-20°C to 65°C). Dial Size: 2.5” (63mm). Connection: 1/4” NPT Bottom connect with restricted orifice. Accuracy: 1.5% of Full Scale Value. Range: 30" Vac/KPA
