Key Features
- Most economical, all-purpose pressure gauge
- Lead free wetted parts
- 2.5" Dial Size
- ±3-2-3% accuracy
- Black steel case
Specifications
| Brand | Winters Instruments |
| Manufacturer | Winters |
| Model | PEM211LF |
| Material | Aluminum,Phosphor Bronze,Polycarbonate,Steel,Brass |
| Color | Bronze,White |
| Style | 0/15 PSI/KPA |
| Product Type | ELECTROMECHANICAL_GAUGE |
| Included Components | Unit and Instruction Guide |
| Item Type Keyword | industrial-pressure-gauges |
| Item Dimensions | H: 25 / L: 89 / W: 64 |
| Package Dimensions | H: 38 / L: 94 / W: 71 (Weight: 113) |
| unit |
Description
Applications: Plumbing, heating, air conditioning, pneumatic, water tanks, air compressors, OEM. Most economical, all-purpose pressure gauge. CRN registered. Warranty: 5 Years. Dial: White aluminum with black and red markings. Case: Steel, painted black. Ring: Steel, painted black. Lens: Polycarbonate. Bourdon Tube: Lead free phosphor bronze. Socket: Lead Free Brass. Movement: Brass. Working Pressure: Maximum 75% of full scale value. Over-Pressure Limit: 25% of Full Scale Value. Enclosure Rating: IP52. Accuracy: ±3-2-3% ANSI/ASME Grade B. Dial Size: 2.5” (63mm). Range: 0-15 PSI/KPA. Connection: 1/4" NPT Bottom Connect.
