⭐ Key Features

•Most economical, all-purpose pressure gauge

•Lead free wetted parts

•1.5" Dial Size

•±3-2-3% accuracy

•Black steel case

🛠️ Specifications

• Brand : Winters Instruments
• Style : 0/100 PSI/KPA
• Material : Aluminum,Phosphor Bronze,Polycarbonate,Steel,Brass
• Unit : 1 Count
• Color : Bronze,White
• Included components : Unit and Instruction Guide
• Number of items : 1
• Package quantity : 1
• Type : ELECTROMECHANICAL_GAUGE
• Item dimensions : H: 1.5 / L: 1.5 / W: 1.5 (Weight: 0.02)
• Package dimensions : H: 2.4 / L: 11.3 / W: 3.4 (Weight: 0.13)

📋 Product Description

Applications: Plumbing, heating, air conditioning, pneumatic, water tanks, air compressors, OEM. Most economical, all-purpose pressure gauge. CRN registered. Warranty: 5 Years. Dial: White aluminum with black and red markings. Case: Steel, painted black. Ring: Steel, painted black. Lens: Polycarbonate. Bourdon Tube: Lead free phosphor bronze. Socket: Lead Free Brass. Movement: Brass. Working Pressure: Maximum 75% of full scale value. Over-Pressure Limit: 25% of Full Scale Value. Enclosure Rating: IP52. Accuracy: ±3-2-3% ANSI/ASME Grade B. Dial Size: 1.5” (40mm). Range: 0-100 psi/kPa. Connection: 1/8" NPT Center Back Connect.
